Airmax manufactures, supplies, and exports 3/2 Foot Operated Detent Spring Return Valves in India and worldwide. These valves are used to control the flow of compressed air in pneumatic systems and are available in a variety of sizes and materials, making them suitable for a wide range of applications.
Some of the key features of these valves include their compact and durable design, easy installation and maintenance. Additionally, the Ad-20 Series is a premium product line that offers even higher quality and performance.
When dealing with complex pneumatic systems, the 5/2 foot operated valve delivers reliable directional control for multi-port configurations.
- Compact Design
- Durable
- Light Weight
- Standard Grade MOC
- Smart International Design Look
- Epoxy Treated Surface
- Replaceable & Repairable Parts
| Technical Specifications |
| Product Name |
3/2 Foot Operated Valves (Detent / Spring Return) |
| Model |
2AD-FS-302 |
| Size |
1/4″ |
| Design |
Poppet Type |
| Pressure |
Upto 10 Kg/cm² |
| Temperature |
Upto 60 ˚C |
| Leakage |
Bubble Tight |
Recommended
for Lubrication |
ISO VG32 (Servo System 32) |
| Flow |
600 LPM |
| Media |
Compressed Air ( Filtered & Lubricated ) |
