Airmax Pneumatics manufactures compact and durable 3/2 way stem actuated valves used to control the flow of compressed air in pneumatic systems. These valves feature a poppet design and are actuated by a stem. They are available in a 1/4 inch size and can withstand a pressure of up to 10 kg/cm2. The valves have a maximum operating temperature of 55 degrees C and are bubble tight at leakage.
By including this additional information, you can provide potential customers with a more comprehensive understanding of your product and its capabilities. Improve your experience with another premium model 5/2 way stem actuated valve, featuring advanced technology and premium materials.
- Compact Design and Durable
- Light Weight
- Standard Graded MOC
- Smart International Design Look
- Epoxy Treated Surface
- Replaceable & Repairable Parts
| Technical Specifications |
| Product Name | 3/2 Way Stem Actuated Valve |
| Model | 2AD-SV-302 |
| Size | 1/4″ |
| Design | Poppet Type |
| Pressure | Upto 10 Kg/cm² |
| Temperature | Upto 60 ˚C |
| Leakage | Bubble Tight |
Recommended
for Lubrication | ISO VG32 (Servo System 32) |
| Flow | 600 LPM |
| Media | Compressed Air ( Filtered & Lubricated ) |
